Marshalling Kiosk Replacements

Winder Power is a leading supplier of marshalling kiosks / remote control kiosks for use in electrical substations and other outdoor applications.

Marshalling kiosks are used to provide convenient connection points for the various control, protection and instrumentation wires which are used in different substation plants.

Our outdoor marshalling kiosks are custom designed for each individual application, whilst the design process ensures that the correct amount of equipment is included for both the current application and also for any future expansion that may be required. The marshalling kiosks / remote interface kiosks can be provided with front and rear access, or in some applications front only access where substation space may be limited.

Key Features:
  • Single or double bay marshalling kiosks
  • Kiosk manufactured from 2.0mm gauge stainless steel grade 316 natural finish
  • Supplied with oil and winding temperature indicators with contacts and capillary length to suit
  • Single or double opening doors at front and back of cabinet as required
  • Up to IP65 protection
  • 3-point locking and metal swing handle with opening for padlock
  • Door stays in each door
  • Document holders
  • External lifting eyes and ground fixing points with anchor bolt kit
  • External breather gland to alleviate condensation
  • Cable management facilities and base gland plates
  • Supplied fully assembled
  • Painted Kiosks available
